ARES 2 E RADIO CONTROL

• Size 143x80x143 mm
• Weight 667 g
• Commands 32 ON/OFF
• Analogic Commands 8

• Secure horn
• NiMH Battery rechargeable power supply 3.6 V DC Special
• IP65 Protection Degree
• Emergency STOP PL e Cat.4 (ISO 13849-1:2006 6.2.7. architecture)

• EN 300-220-2​
• EN 301-489-3
• EN 60950-1

• EN 61000-6-2

• EN 62311

• EN 60204-32

• ISO 13849-1

• UNI EN 13557

• EN 62061



Directives:

• 2006/42/CE
• R&TTE 1999/5/CE
• RED 2014/53/UE
• EMC (2014/30/CE)

Included in the supply of M880 remote control also a new battery charger with a compact and robust design.
Its case is designed to be fixed to the wall and is equipped with 2.1 jack connection for the connetcion to external power through plug.
Two pratical status LEDs provides information about the activation/supply status of the battery charger and about the progress of the charging.
The electronic managemente of the charging process ensure always optimal charging cycles in the shortest time possible.

Technical Features

• Power supply 11÷30 Vdc
• Max power consumption 400 mA
• Tiype of batteries 3,6 V NiMH
• Charging current 900 mA
• Max charging time 2 hours and 45 minutes
• Operating temperature 0°C ÷ +35°C (+41°F ÷ +113°F)
• Storage temperature -40°C ÷ +85°C (-40°F ÷ +185°F)
• Dimensions (WxDxH) 80 x 30 x 120 mm
• Weight 250 g
• Protection degree IP 20

A wide range of switches, buttons ans potentiometers able to meet any demand and customization.

A pratical belt clip allows the operator to completely free the hands to better follow the hitching / release of the crane load.

The tool lets you connect the transmitter or receiver to undergo diagnose to a PC. The data may be visualized by means of an easy and intuitive graphical interface and then be saved on your PC in editable format. Two versions available: STANDARD – tx can be connected to the tool only via cable; PLUS – besides the cable connection, the device can be connected in wireless mode. This way, the diagnosis and programming tasks can be performed even without having access to the connector on the device. (ex: the RX is positioned at the top of a tall crane).

M880 H AC Receiver

• Supply voltage 24Vac (50-60Hz), 68VA, max 2,8A
• 45-240Vac (50-60Hz), 45VA, max 1,1A @45Vac
• Security commands Fino a 6 safety-enable relays, 2 Stop relays
• Max number of ON/OFF commands 73 relays o MOSFET
• Max number of analog commands 32
• Service commands Start, Horn, Timed-relay
• 2 STOP relays ISO 13849-1:2006 6.2.7 architecture (escluso ARES2 C)
• Entrance CAN, serial
• Communications protocol  CAN (ID 11-29 bit) - CANOpen (ID 11-29 bit) - RS232/RS485
• Operating temperature -25°C  +70°C
• Storage temperature -40°C ÷ +85°C
• Dimensions (LxPxA) 205 x 280 x 130 mm
• Degree protection IP66



M880 H DC Receiver

• Supply voltage 11-30Vdc, max 4A @11Vdc, 44W
• Security commands Fino a 6 safety-enable relays, 2 Stop relays
• Max number of ON/OFF commands 73 relays o MOSFET
• Max number of analog commands 32
• Service commands Start, Horn, Timed-relay
• 2 STOP relays ISO 13849-1:2006 6.2.7 architecture (escluso ARES2 C)
• Entrance CAN, serial
• Proportional commands 0÷20mA, 4÷20mA, 0Vdc - (Vdc-3) con Vccmax=28Vdc, 0 ÷ ±10Vdc - PWM 0÷1,4A (F=40÷150Hz; F=200÷600Hz; F=600÷1000Hz), 25%-50%-75% Vcc
• Communications protocol CAN (ID 11-29 bit) - CANOpen (ID 11-29 bit) - RS232/RS485
• Operating temperature -25°C ÷ +70°C
• Storage temperature -40°C ÷ +85°C
• Dimensions (LxPxA) 205 x 280 x 130 mm
• Degree protection IP66

M880 L AC Receiver

• Supply voltage 24-240Vac (50-60Hz), 30VA, max 1,2A @24Vac
• Security commands Safety-enable relay, 2 Stop relays
• Max number of ON/OFF commands 20 relays o MOSFET
• Max number of analog commands 8
• Service commands Start, Horn, Timed-relay
• 2 STOP relays ISO 13849-1:2006 6.2.7 architecture (escluso ARES2 C)
• Entrance CAN, serial
• Communications protocol CAN (ID 11-29 bit) - CANOpen (ID 11-29 bit) - RS232/RS485
• Operating temperature -25°C ÷ +70°C
• Storage temperature -40°C ÷ +85°C
• Dimensions (LxPxA) 145 x 65 x 225 mm
• Degree protection IP66

• Supply voltage 11-30Vdc, max 2A @11Vdc
• Security commands Safety-enable relay, 2 Stop relays
• Max number of ON/OFF commands 20 relays o MOSFET
• Max number of analog commands 8
• Service commands Start, Horn, Timed-relay
• 2 STOP relays ISO 13849-1:2006 6.2.7 architecture (escluso ARES2 C)
• Entrance CAN, serial
• Proportional commands 0÷20mA, 4÷20mA, 0Vdc - (Vdc-3) con Vccmax=28Vdc, 0 ÷ ±10Vdc ,PWM 0÷1,4A (F=40÷150Hz; F=200÷600Hz; F=600÷1000Hz), 25%-50%-75% Vcc
• Communications protocol CAN (ID 11-29 bit) - CANOpen (ID 11-29 bit) - RS232/RS485
• Operating temperature -25°C ÷ +70°C
• Storage temperature -40°C ÷ +85°C
• Dimensions (LxPxA) 145 x 65 x 225 mm
• Degree protection IP66

M880 M AC Receiver

• Supply voltage 12-30 Vdc / 24 Vac (50-60 Hz)
• Security commands STOP, Safety - Enable
• General Commands 24 relè (20 N.O. e 4 N.C./N.O.)
• Service commands Start, Horn (in the 24 relè)
• Entrance CAN, serial
• Communications protocol CAN (ID 11-29 bit) - CANOpen (ID 11-29 bit) - RS232/RS485
• Operating temperature -25°C ÷ +70°C
• Storage temperature -40°C ÷ +85°C
• Dimensions (LxPxA) 180 x 120 x 73 mm
• Degree protection IP20

The flexibility of its external antenna with extension cable allows you to place it at the point of reception. This option will be of great help in overcoming any obstacles to the radio transmission between transmitter and receiver, so as to ensure maximum range and better communication in all conditions of use. The external antenna is supplied in combination with standard cables of different lengths (2.5 m - 5 m - 10 m).

Robust and effective blinking can be directly connected specially dedicated to the relay inside of all our units receivers.Once connected, the flashing light will turn on with the ignition and radio remain operational throughout the period of use to guarantee the communication between transmitter and receiver.

Device group II. Device intended to be used in environments where there is a probability that explosive atmospheres; Level of protection: category 2. Intended use in environmentswhere there is a likelihood that explosive atmospheres caused by gases, vapors, mists or mixtures of air and dust; protection system potentially explosive gas and dust. The unit remains powered and operational in zones 1, 2 (G) and 21, 22 (D);Housing explosion-proof, temperature class 85 ° C; Totally protected against dust and powerful water jets (IP66) box set up with a cable gland 1 "IOS7/1RC and ¾" IOS7/1RC barrier for armored cables with specifications: Ex ATEX Exd ll2GD The C IP 66, Range 70 m without obstacles.

The system MTRS allows each receiver to be able to recognize a maximum of 4 transmitters (series of receivers L and M) and 8 transmitters (series of receivers H), with which to operate one at a time, and each transmitter to operate with a up to 16 receivers simultaneously.

It's also possible, by the function of LOG-ON and LOG-OFF to trade receiver while maintaining control and security. This allows the sharing of equipment by multiple operators.

With this option, you can activate only if you point the remote control toward the trasmittemte 'additional receiver units called iREADY.The transmission of the start signal takes place by means of an infrared beam in combination with the normal radio signal, in fact the transmitter with option iReady is equipped with two LEDs for infrared transmission.

This obliges the operator to perform the start at a certain distance and position relative to the machine, to avoid inadvertent and unwanted goodwill.Once you start, the normal commands work on radio.

The new DSC further improves the accuracy of the proportional movements of cranes and concrete pumps. The operator can correct in real time the levels of the low speed acting on DSC + / - to optimize the response of the machine according to the conditions of the work session.

The device defined "Tilt Sensor", consists of a card that has an accelerometer, which is managed directly by the remote controller, by reading two analog signals. The application for which it was designed requires the automatic shutdown of the transmitter when the transmitter pouch worn by more than an inclination to the horizontal axis of + / - 62 °.

The client can request the automatic shutdown of the remote control for other degrees of inclination up to a maximum of + / - 90 °, as the card has trimmer for calibration of analog outputs. The highest resolution and + / - 28 mV / ° C.
